2024 Argo Magnum XF 500

2024 Argo Magnum XF 500

STANDARD FEATURES

  • 443cc Liquid-Cooled 4-Stroke EFI Engine

  • Automatic CVT with Engine Braking

  • 25" Tires with Steel Rims

  • Front & Rear Independent Double A-Arm Suspension

  • Electronic 2WD/4WD with Front Differential Lock

  • Front & Rear Hydraulic Disc Brakes

  • 1,200 lb Towing Capacity with 2" Receiver

  • 441 lb Rear Cargo Box with Tilt Assist Shock

  • Adjustable Tilt Steering Wheel

  • Dash, Underseat, Underhood and Tailgate Storage

DIMENSIONS

  • Length: 106.3 In (2700mm)

  • Width: 56.7 In (1440mm)

  • Height: 72.8 In (1850mm)

  • Seat Height: 32.9 In (836mm)

  • Ground Clearance: 10 In (254 Mm)

  • Wheelbase: 72 In (1,829 Mm)

  • Towing Capacity: 1,200 Lb (545.5 Kg)

  • Dry Weight: 1,025 Lb (465 Kg)

  • Wet Weight: 1,080 Lb (490 Kg)

  • Fuel Tank Capacity: 8.5 Gal (32 L)

ENGINE

  • Displacement: 443cc

  • Engine Stroke: 4-Stroke

  • Cylinder Arrangement: Sohc Single-Cylinder

  • Valve Configuration: 4 Valve

  • Fuel System: EFI

  • Cooling System: Liquid

  • Bore X Stroke: 89 X 71.2 Mm

  • Compression Ratio: 9.1:1

  • Start Method: Electric Start

  • Ignition: ECU

  • Transmission Type: CVT Automatic

  • Final Drive: Shaft Drive

  • Differential Function: Front Differential

  • Drive System Type: Electronic 2WD/ 4WD/ Lock

  • Electric Diff Lock: Yes

  • Gear Selection: H/L/N/R/P

  • Engine Braking System (EBS): Standard

  • Battery: 12V AGM

CHASSIS

  • Tire Size (Front): At25x8-12 (Maxxis)

  • Tire Size (Rear): At25x10-12 (Maxxis)

  • Wheel Rim: Steel

  • Brake - Front: Dual Hydraulic ​​disc

  • Brake - Rear: Hydraulic ​disc

  • Foot Brake: Yes

  • Suspension: Independent Double A-Arm

  • Front Suspension Travel: 6.9 In (176 mm)

  • Rear Suspension Travel: 6.8 In (172mm)



Local Pick-Up Only: You can come and pick up your new ride at 4425 S. 84th Street, Omaha, Ne 68127

    $10,499.99Price
    Color: Green
