2024 Argo Magnum XF 500

STANDARD FEATURES
443cc Liquid-Cooled 4-Stroke EFI Engine
Automatic CVT with Engine Braking
25" Tires with Steel Rims
Front & Rear Independent Double A-Arm Suspension
Electronic 2WD/4WD with Front Differential Lock
Front & Rear Hydraulic Disc Brakes
1,200 lb Towing Capacity with 2" Receiver
441 lb Rear Cargo Box with Tilt Assist Shock
Adjustable Tilt Steering Wheel
Dash, Underseat, Underhood and Tailgate Storage
DIMENSIONS
Length: 106.3 In (2700mm)
Width: 56.7 In (1440mm)
Height: 72.8 In (1850mm)
Seat Height: 32.9 In (836mm)
Ground Clearance: 10 In (254 Mm)
Wheelbase: 72 In (1,829 Mm)
Towing Capacity: 1,200 Lb (545.5 Kg)
Dry Weight: 1,025 Lb (465 Kg)
Wet Weight: 1,080 Lb (490 Kg)
Fuel Tank Capacity: 8.5 Gal (32 L)
ENGINE
Displacement: 443cc
Engine Stroke: 4-Stroke
Cylinder Arrangement: Sohc Single-Cylinder
Valve Configuration: 4 Valve
Fuel System: EFI
Cooling System: Liquid
Bore X Stroke: 89 X 71.2 Mm
Compression Ratio: 9.1:1
Start Method: Electric Start
Ignition: ECU
Transmission Type: CVT Automatic
Final Drive: Shaft Drive
Differential Function: Front Differential
Drive System Type: Electronic 2WD/ 4WD/ Lock
Electric Diff Lock: Yes
Gear Selection: H/L/N/R/P
Engine Braking System (EBS): Standard
Battery: 12V AGM
CHASSIS
Tire Size (Front): At25x8-12 (Maxxis)
Tire Size (Rear): At25x10-12 (Maxxis)
Wheel Rim: Steel
Brake - Front: Dual Hydraulic ​​disc
Brake - Rear: Hydraulic ​disc
Foot Brake: Yes
Suspension: Independent Double A-Arm
Front Suspension Travel: 6.9 In (176 mm)
Rear Suspension Travel: 6.8 In (172mm)

Local Pick-Up Only: You can come and pick up your new ride at 4425 S. 84th Street, Omaha, Ne 68127
