2024 Argo Xplorer XR 500
STANDARD FEATURES
443cc Liquid-Cooled Engine with EFI
Automatic CVT with Engine Braking
24" Tires with Steel Rims
Electronic Push-Button 2WD/4WD with Front Differential Lock
Front & Rear Independent Double A-Arm Suspension
Front & Rear Hydraulic Disc Brakes
Heavy-Duty Steel Front & Rear Racks
Multifunction Digital Gauge
DIMENSIONS
Length: 75" (1,905mm)
Width: 48.4" (1,230mm)
Height: 47.6" (1210mm)
Seat Height: 33.2" (843mm)
Ground Clearance: 10.2" (260mm)
Wheelbase: 48.2" (1,225mm)
Towing Capacity: 985 Lbs (447 Kg)
Dry Weight: 574 Lbs (260 Kg)
Wet Weight: 604 Lbs (274 Kg)
Fuel Tank Capacity: 4.0 Gal (15 L)
Front Rack: 75 Lbs (34 Kg)
Rear Rack: 150 Lbs (68 Kg)
ENGINE
Displacement: 443cc
Engine Stroke: 4-Stroke
Cylinder Arrangement: Sohc Single-Cylinder
Valve Configuration: 4 Valve
Fuel System: EFI
Cooling System: Liquid
Bore X Stroke: 89 X 71.2mm
Compression Ratio: 9.1:1
Start Method: Electric Start
Ignition: Ecu
Override Button: Standard
Transmission Type: CVT Automatic
Final Drive: Shaft Drive
Differential Function: Front Differential
Drive System Type: 2WD / 4WD / Lock
Electric Diff Lock: Yes
Gear Selection: H/L/N/R
Engine Braking System: Standard
Battery: MF 18AH
12V Charger: DC 12V 10A 120W
CHASSIS
Front Tire Size: AT 24x8-12
Rear Tire Size: AT 24x10-12
Wheel Rim: Steel
Front Brakes: Dual Hydraulic Disc
Rear Brakes: Hydraulic Disc
Foot Brake: Standard
Suspension: Independent Double A-Arm
Suspension Travel: 7.5" (190mm)
Hitch: Standard/2" Receiver
Local Pick-Up Only: You can come and pick up your new ride at 4425 S. 84th Street, Omaha, Ne 68127
